Brief of the Product:

The Havells STADX 63A SPN C MCB (Miniature Circuit Breaker) is a reliable and efficient electrical protection device designed for residential and commercial applications. Rated at 63 Amperes, this Single Pole Neutral (SPN) MCB operates at 240V, offering superior protection against overloads and short circuits.

About this item:

The 'C' curve characteristic allows it to handle higher inrush currents from inductive loads like motors and transformers without nuisance tripping, making it suitable for a wide range of electrical installations.

Rated Current 63 amperes: Provides robust protection for circuits with high current demands, ensuring safety and reliability in managing substantial electrical loads.

Single pole neutral (SPN) MCB: Specifically designed for single-phase systems, it offers effective protection by isolating both the live and neutral conductors, enhancing overall circuit safety.

Voltage 240V: Compatible with standard household and commercial electrical systems, ensuring seamless integration and reliable performance at typical operating voltages.

Curve Type 'C': Capable of handling higher inrush currents from inductive loads, such as motors or transformers, minimizing nuisance tripping and maintaining stability under varying load conditions.

Overload and short circuit protection: Safeguards against potential electrical hazards by automatically disconnecting the circuit during overloads or short circuits, preventing damage to appliances and reducing fire risk.

Product Specifications:

Product Type: C SERIES
Product Line: MCB
Brand: HAVELLS
Model: DHMZCSNF063
Warranty/Guarantee: 6 YEAR
Series: STAD-X
Country of Origin: India
Manufacturer/Importer Name: Havells (India) Ltd.
Sales Unit: PCE
Sub Brand: STAD-X
Base Material: Plastic
Dimension/Size: 62L x 17.7W mm
Weight/Volume: 0.256
Colour Name (CCT): WHITE
Current Rating (AMP): 63 AMP
Breaking Capacity: 10KA
Pole: 1P
Finish: Matt
Series/Sub brands: STADX
Voltage Rating: 240 VOLT
BIS ISI Certificate No: IEC60947-2, EN/IEC/IS 60898-262
Curve Type: C
IP Rating: IP20
BIS Certification: Yes
Assembly Required: Yes
Assembly Type: Expert Required
What is in the Box: 1 MCB, 1 Instruction Manual, 1 Warranty Card
Product Care Instructions: Avoid water exposure and ensure safe electrical connections
Recommended Use of Product: Residential / Commercial
Age Range (Description): Adult
Number of Pcs: 1
Operation Mode: ON-OFF
Connector Type: Clamp
